Space is always an issue when there is a need for broadband operation. Traditional High Power Amplifiers are generally narrow band requiring 2-3 devices plus other components to cover a frequency band such as 2 to 18 GHz. This adds additional insertion loss that reduces or limits the amount of gain and gain flatness that can be achieved.
To overcome this, Quantic PMI has designed this line of high-power amplifiers that are broadband and provide a high gain and remarkably low noise figure across the entire band. This reduces costs by only requiring one device vs several devices to cover the same band.
PA-2G18G-43-5-40-SFF from Quantic PMI
Quantic PMI Model PA-2G18G-43-5-40-SFF is a high-power amplifier designed for a remarkably low noise figure of 3.5 dB and Psat of 40 dBm (10 W) over the 2 to 18 GHz frequency range with a high gain of +43 dB and ±1.5 dB gain flatness.
Part Number | Frequency Range | Gain (dB) | Saturation Output Power | Noise Figure | Package Size | Availability |  | PA-2G18G-43-5-40-SFF | 2 to 18 GHz | 43 dB Typ 39 dB Min | 40 dBm Typ 36 dBm Min | 3.5 dB Typ 5.0 dB Max | 1.3” x 1.8” x 0.88” | Order / Learn More |
|---|
Key Features
This model has SMA connectors and an ultra-small package of 1.3” x 1.8” x 0.88”. Optional model PA-2G18G-43-5-40-SFF-HS available with heatsink and 120 Vac cooling fan.
- Unconditional Stability
- Rugged Construction
- SMA Female Connectors
- Each unit has a unique serial number and date code.
- Swept Data with each unit. (S21, S11, S22 and Noise Figure)
- Summary data sheet with each unit.
- Operating Temperature -55 °C to +85 °C
Options
- Optimized Frequency Bands
- Heatsink and/or Cooling Fan
- Environmental Screening
- Hermetic Sealing
- Custom Packages
- Military or Space Screening
