Peraso Module Total Solution

Eliminates Risk – Shortens Time to Market
RFPD
60GHz mmWave Modules from Peraso

60GHz mmWave Modules from Peraso

Peraso’s Module solutions focus on eliminating the time and cost of designing a module that must be manufactured in high volume and is of high quality and reliability.

Peraso’s mmWave modules provide complete USB 3.0 to 802.11ad solutions for high-speed wireless applications including Fixed Wireless and Enterprise data networking infrastructure. The modules utilize the Peraso X720 and X130 60GHz phased- array chipsets which include a baseband processor and mmWave beamformer transceiver RFICs.

These modules incorporate phased array antennas which offer a variety of gain and field-of-view options. The antennas are integrated into the PCB and provides uniform performance over the entire unlicensed 60GHz band.

Peraso’s Module Solutions

  • Optimized Performance

Eliminates high frequency board design challenges

  • Field-Proven

Proven Manufacturability for quality, reliability and volume

  • Shortens Time to Market
Operating test coverage and testing time
  • Compliant Technology

Pre-scanned for compliance with FCC regulations

  • Eliminates Complex RF Testing

Allow customers for focus on the application not the RF connectivity

Perspectus 60 Series

The Perspectus 60 series of modules utilize Peraso’s high power X720 chipset. The modules are supported by Peraso’s Perspectus Infrastructure software and firmware packages.

Part Number
Antenna Array
Max EIRP
Antenna Gain
Scan range
Digital Interface
Power
PRM2141X-V-EGS
16-element. V-pol
37 dBm
15 dBi
±45° azimuth
±45° elevation
USB 3.0 data and control.
2.5V CMOS 1PPS Sync and GPIO.
Tx: 7-11.75 W; Rx: 4.5 W
PRM2142X-V-EGS
32-element. V-pol
40 dBm
18 dBi
±45° azimuth
±25° elevation
USB 3.0 data and control.
2.5V CMOS 1PPS Sync and GPIO.
Tx: 11.75 W; Rx: 4.5 W
PRM2143X-V-EGS
64-element. V-pol
44 dBm
22 dBi
±20° azimuth
±15° elevation
USB 3.0 data and control.
2.5V CMOS 1PPS Sync and GPIO.
Tx: 11.75 W; Rx: 4.5 W
PRM2144X-V-EGS
128-element. V-pol
+46 dBm
24 dBi
±10° azimuth
±20° elevation
USB 3.0 data and control.
2.5V CMOS 1PPS Sync and GPIO.
Tx: 11.75 W; Rx: 4.5 W

Versatus 60 Series

Versatus 60 series module is targeted for enterprise, industrial and consumer applications which demand reliable, low latency, multi-gigabit data rates.

It incorporates antenna arrays which can switch between vertical and horizontal polarizations to match any installation or operational scenario.

Part Number
Antenna Array
Max EIRP
Antenna Gain
Scan range
Digital Interface
Power
PRM2136X-CGF
8+8 element dual polarized patch
29 dBm
13 dBi
±45° azimuth
±40° elevation
USB 3.0 data and control.
2.5V CMOS 1PPS Sync and GPIO.
Tx: 3.2 W; Rx: 2.9 W

Additional Resources

60GHz mmWave Modules Selection Guide

Peraso offers its Perspectus 60 and Versatus 60 module series for the 60GHz band.

60GHz mmWave Modules Selection Guide

Perasus modules offer low latency, high reliability, multi-gigabit throughput and can be configured to support Peraso’s unique capabilities that enable point-to-point and point-to-multipoint Fixed Wireless applications with link ranges exceeding 25 kilometers.
View Selection Guide

Fixed Wireless Access for Unlicensed 60GHz with Perspectus Modules

As consumer demand for data bandwidth grows worldwide, service providers face difficult challenges to expand capacity and coverage.

Application Note: Fixed Wireless Access for Unlicensed 60GHz with Perspectus Modules

Fixed Wireless Access Systems have overcome many service provisioning challenges...
View Application Note
