Adapters

Adapters are often used for Test & Measurement applications, for production and in the lab.  They are also used in the field in a variety of communication systems applications.  Performance grades range from low-cost commercial to rugged military. They can also be used in the field in a variety of communication systems applications (e.g., connecting two shorter cables together to make one longer cable).  Adapters come in Straight, Right-Angle, Bulkhead / Panel Mount, and Tee configurations.

Carlisle Interconnect Technologies

This RF straight adapter features an SMP-SMP adapter style, jack-jack body/shell style and characteristic impedance of 50 Ohms.

  • RoHS-compliant
  • Contact material: Beryllium copper
  • Durability: 5000 cycles
  • VSWR: 1.7:1

HUBER+SUHNER

This within series RF adaptor is a bulkhead adaptor SMA jack (female) / SMA jack (female) featuring a hermetically sealed connector.

  • Impedance: 50 Ohms
  • Interface frequency max: 18 GHz
  • Return loss @ 0–3 GHz: 26 dB
  • Return loss @ 7–18 GHz: 17 dB

HUBER+SUHNER

This within series RF adaptor is a bulkhead adaptor SMB jack (female) / SMB jack (female).

  • Impedance: 50 Ohms
  • Interface frequency max: 4 GHz
  • Interface standard
  • Return loss: ≥19 dB

Carlisle Interconnect Technologies

This RF coaxial adapter has a continuous right-angled design for optimally matched low loss adapters for 50 Ohm applications with low VSWR and insertion loss.

  • Frequency: 18 GHz
  • SMA male/SMA female
  • Max VSWR: 1.25:1
  • Length: 0.55 in

Featured Manufacturers  Adapters
