Wolfspeed - CRD30DD12N-K Reference Design

30kW, 3-Phase Interleaved LLC DCDC Converter Reference Design Targets Fast Charger Applications
Wolfspeed CRD30DD12N-K Reference Design

Wolfspeed CRD30DD12N-K Reference Design

Mfg Part No: CRD30DD12N-K

Wolfspeed’s 30kW 3-phase interleaved LLC DCDC converter (CRD30DD12N-K) targets high-power-density, high-efficiency fast charger applications and features Wolfspeed’s discrete 1200V C3M Silicon Carbide MOSFETs (C3M0040120K) and 650V C6D Silicon Carbide Schottky Diodes (C6D20065D and C6D10065A). The reference design accommodates all different levels of EV charging with a wide output voltage range of 200V-1000V while maintaining a high power density of 6.5kW/L and higher than 98% peak efficiency…
