Guerrilla RF – GRF2133: Low Noise Amplifier

0.1 – 2.7 GHz, 28.0 dB gain, +20.0 dBm P1dB, 1.5 x 1.5 mm DFN-6
RFPD
Guerrilla RF: GRF2133 Ultra-High Gain LNA

Guerrilla RF: GRF2133 Ultra-High Gain LNA

Covers 0.1 to 2.7 GHz

The GRF2133 is a broadband linear gain block low noise amplifier featuring ultra-high gain and sub 0.85 dB noise figure for small cell, cellular booster, wireless infrastructure and other high performance applications.

Configured as a linear driver, LNA or cascaded gain block, it offers high levels of reuse both within a design and across platforms. The device is operated from a supply voltage of 1.8 to 5.0 V with a selectable Iddq range of 35 to 120 mA for optimal efficiency and linearity.

Order / Learn More
Ask an Engineer
Guerrilla RF Logo

GRF2133 - Guerrilla RF

All Guerrilla RF products are provided in RoHS compliant lead (Pb)-free packaging requiring no exemptions.

Frequency Range
P1dB
Gain
IP3
Noise Figure
Bias Voltage
Bias Current
0.1 – 2.7 GHz
+20 dBm
28 dB
+31 dBm
0.6 dB
5 V
60 mA

Features

  • Internally Matched
  • Unconditionally Stable
  • Flexible Biasing
  • Process: GaAs pHEMT
  • Compact 1.5 x 1.5 mm DFN-6 Package

    • Applications

  • High Gain LNA
  • Cellular Boosters / Repeaters
  • Linear Driver Amplifier

    • RF & Microwave Support
