Analog Devices - EVAL-ADuM4146

High Voltage, Isolated SiC Gate Driver Optimized for Use with Wolfspeed SiC MOSFETs & Power Modules
RFPD
EVAL-ADUM4146

EVAL-ADUM4146

Mfg Part No: EVAL-ADUM4146WHB1Z

The EVAL-ADuM4146WHB1Z is a half bridge gate drive board that allows simple evaluation of the performance of the ADuM4146 when driving advanced Wolfspeed third generation C3M™ silicon carbide (SiC) metal-oxide semiconductor field-effect transistors (MOSFETs) and power modules. The EVALADuM4146WHB1Z is intended to be used in conjunction with Wolfspeed clamped inductive load (CIL) test boards or half bridge evaluation boards and differential transceiver boards.

Order Now

Features

  • Optimized for use with Wolfspeed SiC MOSFETs and power modules
  • Compatible with Wolfspeed CIL test boards and half bridge evaluation boards
  • High frequency, ultrafast switching operation
  • Input and output side UVLO
  • Short-circuit protection
  • Shoot-through protection interlock
  • Internal Miller clamp
  • Differential inputs for increased noise immunity
  • Fault and ready indicators
  • Isolated NTC thermistor measurement

    • Analog Devices Logo
