Analog Devices - EVL-ADUM4120EBZ

Evaluation Board for Isolated Precision Gate Drivers
Evaluation Board for Isolated Precision Gate Drivers

Evaluation Board for Isolated Precision Gate Drivers

Mfg Part No: EVAL-ADUM4120EBZ

Analog Devices’ EVAL-ADuM4120EBZ supports the ADuM4120 single-channel gate drivers with 150kV/usec CMTI, 2A peak drive output capability and low propagation delay (< 51 ns). ADI’s iCoupler® technology provides isolation between the input signal and the output gate driver. The EVAL-ADuM4120EBZ is populated with the ADuM4120ARIZ which has 4.4V UVLO.

The ADUM4120 provides operation with voltages of up to 35 V. The high common-mode transient immunity (CMTI) and robust drive strength makes the ADUM4120 an excellent fit for fast switching technologies.


  • 2 A peak drive output capability
  • Output power device resistance: <2 Ω
  • Low propagation delay: <51 ns
  • Operating temperature range: −40°C to +125°C
  • Output voltage range to 35 V
  • Output and input undervoltage lockout (UVLO)
  • Pad placement for multiple switch types
  • Screw terminals for easy connectivity
  • Related Content


    Analog Devices EVAL-ADuM4146: High Voltage, Isolated SiC Gate Driver Optimized for Use with Wolfspeed SiC MOSFETs & Power Modules
